The compressor is a kind of speed booster box and compressor cylinder shell in one centrifugal compressor, the motor through the diaphragm type coupling to drive the compressor input shaft of the large gear, and then driven by the high speed (gear) shaft and its meshing. High-speed shaft installed at one end of the first impeller, the other end of the installation of the second impeller, two-stage impeller are placed in its cylinder. Each stage of the compressor's cylinder is independent, respectively, fixed on both sides of the gear box body.

MVR（Mechanical Vapor Recompression）Short for mechanical vapor recompression, it uses mechanical compression to raise the temperature and enthalpy of the secondary steam generated during the evaporation and concentration process to achieve the heat transfer temperature difference required for operation, and to realize the reuse of low-temperature and low-pressure secondary steam. The latent heat of the low-temperature and low-pressure secondary steam is recovered with a small amount of electric energy. Thus, energy saving and emission reduction are realized and production costs are reduced.

Turbine expander refrigeration principle is the use of a certain pressure of the gas in the turbine expander adiabatic expansion of external work and consumption of the internal energy of the gas itself, so that the gas itself is strongly cooled to achieve the purpose of refrigeration. At present, it is mainly used in the fields of oilfield gas light hydrocarbon recovery, chemical tail gas treatment, and residual pressure and heat power generation.

This product is based on the chlorine gas turbine compressor, downward extension of the development of MVR compressor series products, its structure, principle, design and processing and manufacturing are along the higher requirements of the chlorine gas compressor and MVR compressor, its efficiency, performance, quality and reliability are fully guaranteed.

This product is based on the chlorine gas turbine compressor, drawing on foreign advanced air compressor technology development and design of all oil-free air compressor.
